P C Henderson S5 Marathon Sliding Door Gear Set
SKU: IJ117115
The Marathon kit manufactured from aluminium, offers a unique system that operates on a solid alloy roller bar and one piece ball cage design sliding mechanism for entrance doors and room dividing wooden doors. Designed for timber, timber framed or composite doors, the door gear is suitable for doors with a width range of 1050-1200mm with a track length of 1981mm. The kit supports doors that weigh up to 90kg, and the self-closing door kit can also be added to further complement the system.
Features & benefits
- Ensures a smooth glide operation
- Virtually no maintenance required
- Two kits required for double doors
- Optional self close kit available
- Easy and rapid installation
- Can be combined with Marathon Fire rated to create an FD30 fire door assembly (S3, S4, S5 and S6 kits only)
- Track Length: 1981mm
- Optional self close kit available
IDIJ117115
Door Hardware & Closers > Sliding Door Hardware > Sliding Gears > P C Henderson S5 Marathon Sliding Door Gear Set
https://www.george-boyd.co.uk/p/henderson-marathon-senior-sliding-door-gear-set-s5-IJ117115
The Marathon kit manufactured from aluminium, offers a unique system that operates on a solid alloy roller bar and one piece ball cage design sliding mechanism for entrance doors and room dividing wooden doors. Designed for timber, timber framed or composite doors, the door gear is suitable for doors with a width range of 1050-1200mm with a track length of 1981mm. The kit supports doors that weigh up to 90kg, and the self-closing door kit can also be added to further complement the system.
Features & benefits
- Ensures a smooth glide operation
- Virtually no maintenance required
- Two kits required for double doors
- Optional self close kit available
- Easy and rapid installation
- Can be combined with Marathon Fire rated to create an FD30 fire door assembly (S3, S4, S5 and S6 kits only)
- Track Length: 1981mm
- Optional self close kit available
Specifications
| Product Name | P C Henderson S5 Marathon Sliding Door Gear Set |
| Brand | Henderson |
| Manufacturer Name | P C Henderson Ltd |
| Manufacturer Part Number | 789613 |
| EAN | 5019879003468 |
| Compliance Approvals | ISO 14001 |
| Materials |
Aluminium
Nylon |
| Commercial Or Domestic Use | Both |
| Range | Sliding Door Gear |
| Model Number | S5 |
| Application | Interior |
| Pack Quantity | 1 |
| Country Of Origin | United Kingdom |
| Finish | 0 |
| Product Weight | 90 kg |
| Product Length | 1981 mm |
